Product Description
Canri's drain drain gratings are designed for both residential and industrial applications, ensuring superior durability andsafety. whether you need stainless steel grating for your HDB projects, LTA infrastructure, or PuB drainage solutions, ourproducts are engineered to meet Singapore's strict quality standards.
The HDG grating of Canri wire Mesh is very popular in the singapore market. we have cooperated with two big singaporeconstruction companies for 5 years. We could produce many types of singapore drain gratings. we are leader supplier ofSingapore Hbc drain gratings.
Our stringent quality control system ensures that our products meet the reguirements of the singapore standards (ssand the standards of the respective authorities, namely HDB, LTA and PuB and other international standards.
Compare the designs below before selecting your drain cover. Listed dimensions identify existing product examples; the frame dimensions, clear opening and load suitability should be confirmed separately.
Drain Grating Type | Listed Size, L × W |
Vehicular Drain Grating | 859 × 578 mm |
House Drain Grating | 1800 × 300 mm |
Hinged House Drain Grating | 1800 × 300 mm |
Flat-Profile House Drain Grating | 1800 × 300 mm |
Stainless Steel Drain Grating | Enquire with your drawing |
Choose your grating according to how the area is used, how the panel is supported and how the drain will be maintained.
Application | Starting Point for Selection | Details to Confirm |
Residential perimeter drains | House drain grating or flat-profile cover | Drain width, seating depth, opening size and removal access |
Footpaths and pedestrian areas | Grating with an opening arrangement suited to pedestrian use | Footwear, wheeled access, surface requirements and finished levels |
Driveways and vehicle crossings | Vehicular grating selected for the specified loading | Wheel loads, clear span, bearing direction and frame support |
Industrial drainage | Configuration selected for the operating environment | Traffic, exposure, cleaning conditions and maintenance frequency |
Drains requiring frequent cleaning | Hinged cover where the installation permits | Opening direction, hinge clearance and access to the channel |
Replacement of existing covers | Grating matched to the existing opening and support | Actual site measurements, frame condition and installation tolerances |
For custom drain grating enquiries, include the following details so the requested configuration can be reviewed:
· Dimensions and layout: Panel sizes, drain lengths, quantities and any changes in direction.
· Material and finish: Required steel or stainless steel grade and surface treatment.
· Bar arrangement: Bearing bar size, pitch, cross bar layout and clear openings.
· Frame details: Existing or new frames, seating depth and fixing locations.
· Opening arrangement: Hinged or removable design, opening direction and access space.
·Special features: Cut-outs, lifting points, locking details or other drawing requirements.
Choosing Canri as your Drain Gratings supplier ensures you receive high-quality, durable, and customized drainage grating solutions. Here’s why you should choose us:
Over 15 Years of Expertise: With more than 15 years in the metal steel works industry, Canri offers a one-stop solution from design and production to installation, catering to various infrastructure project needs.
Expert Designers: Our team has strong design capabilities, including advanced 3D drawing skills, ensuring we deliver tailored solutions to meet your specific requirements.
Certified Welders: Our welders are highly experienced and hold professional welding certifications, ensuring the structural integrity and reliability of our products.
Precision Manufacturing: All welding residues are ground off, and the surfaces are smooth. Zinc slag is thoroughly cleaned, ensuring products are flawless and meet high-quality standards.
Durability: Our steel gratings are built to withstand high loads, adapting to various harsh environments, providing long-lasting performance.
Automated Production: Equipped with two large-scale pressure welding production lines, we achieve efficient, precise automated welding, ensuring consistent product quality and high production capacity.
We provide customized drain grating solutions for different applications, including HDB projects, LTA infrastructure, and PUB drainage systems, meeting your specific needs.
Public Infrastructure: We supply high-performance drain gratings for LTA roads, PUB drainage systems, and HDB residential areas in Singapore.
Industrial Use: Heavy-duty gratings for high-load traffic and industrial zones, ensuring long-term operation under heavy traffic.
Residential and Commercial Projects: Suitable for private residential developments and commercial buildings, combining aesthetics with functionality.
By choosing Canri Wire Mesh Drain Gratings Singapore, you’ll benefit from professional design, high-quality products, and customized solutions that help achieve more efficient and safer infrastructure. Contact us today to learn more about our customized drainage grating solutions.
Types of singapore Grating
Applications: Commonly used in HDB public housing projects, residential area roads, driveways, and walkways.
Features: High compressive strength, ideal for areas with frequent pedestrian and light vehicle traffic.
Load Capacity: Can withstand a maximum load of 1-2 tons per axle.
Vibration Dampening: Provides basic vibration dampening to reduce road impacts from vehicle movements.
Corrosive Environment: Available in galvanized steel or stainless steel, making it suitable for coastal areas or regionswith heavy rainfall.
Vehicular grating 859L x 578W MM
Vehicular grating 859L x 578W MM
House Drain Grating With Hinge 1800L X 300W mm
House Drain Grating 1800L X 300W mm
House Drain Grating Flat profile 1800L X 300W mm
Packing & Loading
Frequently Asked Questions (FAQ)
A1: Drain grating is a metal grate used to cover drainage systems, channels, and ground drainage openings. Typically made from steel, stainless steel, or aluminum, drain gratings not only prevent debris from entering the drainage system but also enhance the load-bearing capacity of the structure.
A2: Steel grating is more economical but tends to rust over time. It is best suited for dry environments or areas with minimal exposure to water. Stainless steel grating, on the other hand, is highly corrosion-resistant and is ideal for coastal areas, humid environments, or areas that need to withstand heavy traffic loads.
A3: The load-bearing capacity of the grating varies by type:
· HDB Grating: Can support 1-2 tons per axle.
· LTA Grating: Can support 5-10 tons per axle.
· PUB Grating: Suitable for regular traffic, with a load capacity of 2-3 tons per axle.
A4: Our steel and stainless steel gratings are made with corrosion-resistant materials, making them ideal for use in Singapore's humid and corrosive environments. They ensure long-term use without rusting, even in challenging conditions.
Contact Canri Wire Mesh today to learn how our corrosion-resistant gratings, made to meet singapores qualitystandards, can benefit your project. whether for residential areas with light vehicle traffic or public roads requiring heayyload traffic support, we provide the best solution for your needs.
